Haihao Group Ships ASTM A420 WPL6 Seamless Butt Weld Fittings to Singapore
Haihao Group has completed fabrication and shipment of ASTM A420 WPL6 seamless butt weld fittings for a Singapore industrial piping project. This batch includes seamless concentric reducers and seamless reducing tees, all built to ASME B16.9 for low-temperature carbon steel pipeline service.
A420 WPL6 seamless concentric reducer and reducing tee ASME B16.9
Product Specification Table
| Product | Size | Wall Thickness | Material | Standard | End / Surface & Marking |
| Seamless Concentric Reducer BE | 2” x 1” | S40 x S80 | A420 Gr WPL6 | ASME B16.9 | Bevel end, black paint, 25mm white RAL9010 NACE band |
| Seamless Concentric Reducer BE | 8” x 6” | S40 x S40 | A420 Gr WPL6 | ASME B16.9 | Bevel end, black paint, 25mm white RAL9010 NACE band |
| Seamless Concentric Reducer BE | 4” x 3” | S80 x S80 | A420 Gr WPL6 | ASME B16.9 | Bevel end, black paint, 25mm white RAL9010 NACE band |
| Seamless Reducing Tee BE | 12” x 8” | STD x S40 | A420 Gr WPL6 | ASME B16.9 | Bevel end, black paint, 25mm white RAL9010 NACE band |
Each ASTM A420 WPL6 concentric reducer comes with precision machined bevel ends ready for site butt welding. The supplied concentric reducer sizes cover 2” x 1”, 8” x 6” and 4” x 3”, with mixed wall schedules S40 x S80, S40 x S40 and S80 x S80. Our workshop applied black paint for rust protection, plus a 25 mm wide white RAL 9010 NACE colour band on every fitting, as specified by the Singapore client.
Alongside the reducers, we delivered one seamless reducing tee sized 12” x 8”, STD x S40, also ASTM A420 WPL6 and manufactured to ASME B16.9. Consistent marking and surface treatment were applied on the reducing tee, matching the same NACE identification requirement for full batch traceability.
The ASTM A420 WPL6 concentric reducer is widely selected for low-temperature piping. We strictly control material testing, dimensional tolerance and marking execution before shipment. Our QA team verifies each fitting to confirm the white RAL9010 NACE stripe, black coating quality and bevel end geometry meet the project’s technical drawing.
When you source ASME B16.9 low temperature fittings for Singapore or Southeast Asia projects, Haihao Group can produce ASTM A420 WPL6 concentric reducer and reducing tee with custom marking, painting and full material certification. We handle special colour marking requirements to align with NACE specifications for oil, gas and chemical pipeline systems.
