ASME B16.9 A420 WPL6 & A860 WPHY65 Pipe Fittings Shipped to UAE
Large-bore low-temperature pipeline construction in the UAE requires heavy-wall seamless fittings that maintain stable toughness under harsh service conditions. Haihao Group has finished production and shipment of large size butt weld fittings including elbows and reducers for an UAE energy project, with batches of A420 WPL6 pipe elbow paired with high-strength A860 WPHY65 bends, fully tested for low-temperature impact requirements.
Large bore ASME B16.9 A420 WPL6 and A860 WPHY65 seamless elbows & reducers shipped to UAE low temperature piping project
Product Specification Table
| Description | Size | Wall Thickness | Material | Standard |
|---|---|---|---|---|
| 90° LR BW Elbow | 14″ | SCH20 | A420 WPL6 | ASME B16.9 |
| 90° LR BW Elbow | 16″ | SCH20 | A420 WPL6 | ASME B16.9 |
| 45° LR BW Elbow | 16″ | SCH20 | A420 WPL6 | ASME B16.9 |
| 90° LR BW Elbow | 18″ | 14.03mm | A860 WPHY65 | ASME B16.9 |
| 90° LR BW Elbow | 20″ | SCH100 | A420 WPL6 | ASME B16.9 |
| 90° LR BW Elbow | 20″ | 17.10mm | A860 WPHY65 | ASME B16.9 |
| 90° LR BW Elbow | 20″ | SCH80 | A420 WPL6 | ASME B16.9 |
| 90° LR BW Elbow | 24″ | SCH20 | A420 WPL6 | ASME B16.9 |
| Concentric Reducer | 14″×10″ | SCH20 | A420 WPL6 | ASME B16.9 |
| Eccentric Reducer | 16″×10″ | SCH20 | A420 WPL6 | ASME B16.9 |
| Eccentric Reducer | 24″×16″ | SCH20 | A420 WPL6 | ASME B16.9 |
Test requirement: A420 WPL6 -46℃ impact 27J; A860 WPHY65 min 40J, avg 34J; S＜0.01%
This shipment covers LR butt-weld elbows and seamless reducers built to ASME B16.9. The A420 WPL6 pipe elbow includes 90° and 45° long radius variants, ranging from 14 inch up to 24 inch with SCH20, SCH80 and SCH100 wall thickness options. Material certification for the A420 WPL6 pipe elbow meets -46℃ impact requirements at 27J, and sulfur content controlled below 0.01% to reduce brittlement risk in cryogenic service.
Complementing the low-temperature carbon steel components, the package also supplies A860 WPHY65 large bore elbows at 18″ and 20″. These high-strength elbows deliver impact energy of 40J minimum and 34J average, designed for high-pressure transmission pipelines. Beside elbows, we also supply concentric and eccentric reducers made from A420 WPL6 for smooth diameter transition across the piping system. Each A420 WPL6 pipe elbow and reducer passes dimensional inspection and material verification before packing.
Haihao Group can manufacture custom large bore ASME B16.9 fittings for Middle East energy projects. We provide full material test reports including low temperature impact test records, chemical analysis with strict sulfur control. If you are sourcing large size A420 WPL6 pipe elbow or high grade A860 WPHY65 butt weld fittings for your pipeline project, feel free to send your technical specification for quotation.
